Medical White MW-3-FVS & MW-7-FPS - Fixed 15.1 Amp 1/2 HP 125 VAC Vacuum Switch & Pressure Switch

MSRP: $2990
$1595
products.you_save_opening_text $13.95 products.you_save_closing_bracket

Please allow 7 to 10 weeks for delivery.

  • Available to Ship Today*:
  • Available to Ship Tomorrow*:
  • Available to Ship in 5 Days*
  • Available to Ship in 7 Days*:

Please call 800-799-4568 or email to confirm availability.

Part #: MW-3-FVS-MW-7-FPS

Description

Vacuum only please, positive pressure will damage the switch.

MW-3-FVS Series - Fixed 15.1 Amp 1/2 HP 125 VAC Vacuum Switch is designed for the customer with cost and space limitations. Electrical boot and mounting bracket come standard.

Specifications

  • Contact Form: Single Pole, Double Throw
  • Terminations: .187 Quick-Connect
  • Agency Compliances: UL / CSA Approved Microswitch
  • Operating Speed: 25 MSEC
  • Materials:
    • Body: Polysulfone1
    • Diaphragm: "Buna"-U-Cup
    • Spring: Stainless Steel1
    • Other: Nylon, Carbon Filled Nylon1, Acetal
  • Temperature Range: 40° - 150° F (4° - 66° C)
  • Activation Set Point: 3"Hg ±1"Hg
  • Max Vacuum: 29.92" Hg
  • Positive Pressure: None
  • Switching Tolerance: ±1"Hg
  • Weight: 18 grams
