SMC CA2-B10 double clevis bracket, CA1/CA2 TIE-ROD CYLINDER

Air cylinder series CA2 has been introduced with specifications and dimensions equivalent to the existing CA1 series. Several improvements have been made to the CA2 series including lateral load improvement, increase in cushioning capacity and adoption of?a new cushion seal. There has been enhanced efficiency in handling for cushion valve adjustment, and weight has been reduced by 5 to 15%. Stock control of the compact auto switches is easy, since a wide variety of auto switches are available.

• Double acting, single rod, standard type
• Bore sizes (mm): 40, 50, 63, 80, 100
• Standard strokes (mm): 25 to 700
• Maximum operating pressure: 1.0MPa
• Auto switch capable
